Isolation Transformer

• Capacity
• 1kva to 5kva

• Coil Material
• Copper Core

• Coil Number
• Toroidal Transformer

• Coil Structure
• Isolation

• Efficiency
• 95%

• Frequency (MHz)
• 50HZ

• Material
• Copper / Aluminum

• Operating Temperature
• 65

• Output
• 230v

• Phase
• Single Phase

• Product Type
• Isolation Transformer

• Rated Voltage
• 230v

• Standard
• IS 9815

• Usage
• Industrial/ domestic

• Warranty
• 2years

• Weight
• 15kg

• Capacity
• 5 kVA

• Coil Material
• Other , Electrolytic Copper

• Coil Number
• Other, Double wound

• Coil Structure
• Other, Toroidal / Layer Wound

• Cooling Type
• Air Natural Cooled (AN)

• Dimension (L*W*H)
• Approx. 480 mm x 380 mm x 450 mm

• Efficiency
• 95% Approx.

• Frequency (MHz)
• 50 Hz (0.05 MHz)

• High Voltage
• 260V AC

• Load Loss
• Low (Typically <2%)

• Low Voltage
• 180V AC

• Material
• High-grade CRGO Silicon Steel, Copper windings

• Operating Temperature
• -10C to +50C

• Output
• 220V / 230V AC

• Phase
• Other, Single Phase / Three Phase

• Power Scope
• 5000 VA (5 kVA)

• Product Type
• Other, Ferro Resonance Constant Voltage Transformer

• Rated Voltage
• Input: 180V-260V AC, Output: 220V / 230V AC

• Standard
• IS 9815 / IEC 60076

• Usage
• Voltage Stabilization for sensitive electronic equipment

• Voltage Booster Type
• Other, Ferroresonant Voltage Regulator

• Weight
• Approximately 55-75 kg

• Capacity
• 200 KVA

• Coil Material
• Other , Copper or Aluminum (as specified)

• Coil Number
• Other, Multiple (Three sets - one per phase)

• Coil Structure
• Laminated Core

• Cooling Type
• Oil Cooled

• Dimension (L*W*H)
• Typically 1200mm x 1000mm x 1600mm (varies by design)

• Efficiency
• High (typically above 98%)

• Frequency (MHz)
• 50/60 Hz

• High Voltage
• Up to 11kV (as per design)

• Load Loss
• <2% at full load

• Low Voltage
• 415V, 400V, or as per requirements

• Material
• High-grade electrical steel, copper/aluminum windings

• Operating Temperature
• -10C to +50C

• Output
• 200 KVA, 3 Phase AC

• Phase
• Other, 3 Phase

• Power Scope
• 200 KVA

• Product Type
• Isolation Transformer

• Rated Voltage
• Customizable (commonly 415V/380V/220V depending on requirement)

• Standard
• IS 2026 / IEC 60076

• Usage
• Industrial Power Isolation

• Voltage Booster Type
• Other, Not applicable for isolation transformer

• Weight
• Approx. 650-850 kg (varies by manufacturer)

• Capacity
• 20 kVA

• Coil Material
• Other , High Grade Copper

• Coil Number
• Double Winding

• Coil Structure
• Laminated Core

• Cooling Type
• Air Cooled

• Dimension (L*W*H)
• Approx. 550mm x 450mm x 900mm

• Efficiency
• 98-99%

• Frequency (MHz)
• 50/60 Hz

• High Voltage
• 415V

• Load Loss
• Low (<2%)

• Low Voltage
• 220V

• Material
• Copper/CRGO Silicon Steel Core

• Operating Temperature
• -10C to +45C

• Output
• 20 kVA

• Phase
• Three Phase

• Power Scope
• 20 kVA

• Product Type
• Other, Air Cooled Isolation Transformer

• Rated Voltage
• 415V / 220V (customizable)

• Standard
• IS 2026/IEC 60076

• Usage
• Electrical isolation and voltage transformation

• Voltage Booster Type
• Other, Step Up / Step Down (as required)

• Weight
• Approx. 120-180 kg
